Application:
1. Adopted to indoor or outdoor distribution.
2. Small cable size,lightweight
3. With excellent waterproofing performance.
Characteristics:
1. Filler protect bube fiber.
2. E-glass member potentiate.
3. Fiber counl:2-12
Technical Specification
| CableCount | Outsheath Diameter | Weight | Minimumallowable Tensile Strength（N） | Minimumallowable Crush Load(N/100nm) | Minimum Bending Radius(MM) | |||
| (MM) | (kg) | Short term | Long term | Short term | Long term | Short term | Long term | |
| 2-12 | 6.0 | 45 | 600 | 200 | 1000 | 200 | 20D | 10D |
Packing Information
| Model No. | OD(mm) | Km/Reel | N.W./Reel(kg) | Reel Size(kg) | Weight for Package by Drum(kg) | Weight for Package by Polywood (kg) |
| GJFXTKV | 6.5 | 6 | 90 | 55*75 | 125 | 120 |
Remark:
Package by Drum needs to be fumigated or provide fumigation certificate when exporting
While, package by Polywood can be exported directly.
